Dell Poweredge R720xd 3.5"
|
The
Dell R720xd server supports a wide array of configurations and form
factors to fit your needs.
E5-26xx or E5-26xxv2
series, dual
CPU capable
24 DIMM slots
384 Gb max utilizing PC3-8500 thru 14900r
registered DIMMs.
4R DIMMs have limitations (max of 18).
768 Gb max utilizing load reducing dimms
PC3-10600L thru PC3-14900L 4R dimms
Supports 3.5" x 12 drive drives - SATA, SAS, SSD
Backplane - 3.5" x 12 standard with an
optional 2.5" x 2 rear drive module ($300 extra).
Lifecycle v2 included in motherboard. This is the brains of
the motherboard.
Risers - 6x PCIe 3.0
one half height and one full height PCIe expansion slots
three half eight PCIe expansion slots
Raid controllers - H310, H710, H710p mini mone daughter cards
Power supplies - Dual 495, 750, 1100 watt. Power
supply wattage must match.
iDRAC7 - express is standard, optional enterprise
(enterprise is software enabled
using a uniquely generated key)
Ethernet - swappable daughter cards - Intel or Broadcom with
support for 1Gb or 10Gb (RJ45 or SFP+ optical ports)
SCSISTUFF
carries most current and previous generation Dell servers. All of our
servers are built to your specifications, updated to the latest
firmware versions & tested.
Call 1 888 712-0717 to purchase or
request a customized quote
Open Monday - Friday 9am - 6pm CT
Email: [email protected] |
Base configuration
3.5" x
12 chassis, (no cdrom installed)
Perc H710 (512 Mb
cache) with battery backup cache
iDRAC7 express
Quad port 1 Gb (RJ45) ethernet
daughterboard installed
Dual
750 watt power supply with 2x power cords
All drives are Dell enterprise
SAS drives
Memory configurations
128Gb
- 16 x 8 Gb PC3-10600R matched dimms
192Gb
- 24 x 8 Gb PC3-10600R matched dimms
256Gb
- 16 x 16 Gb PC3-12800R matched dimms
384Gb
- 24 x 16 Gb PC3-12800R matched dimms
2x E5-2660v2 10C 2.2 Ghz 256 Gb 6x 3 Tb NL-SAS -
$3,795
2x E5-2660v2 10C 2.0 Ghz 384 Gb 12x 4 Tb NL-SAS -
$4,994
E5-2640v2 2.0 Ghz 8C processors
128 Gb 3x 300 Gb 15K - $1499
128 Gb 3x 600 Gb 10K - $1529
128 Gb 3x 2 Tb SATA 7200 rpm - $1529
128 Gb 3x 4 Tb SATA 7200 rpm - $1734
128 Gb 3x 3 Tb NL-SAS 7200 rpm - $1549
128 Gb 3x 4 Tb NL-SAS 7200 rpm - $1769
128 Gb 3x 6 Tb NL-SAS 7200 rpm - $1989
192 Gb 3x 300 Gb 15K - $1895
192 Gb 3x 600 Gb 10K - $1845
192 Gb 3x 2 Tb SATA 7200 rpm - $1614
192 Gb 3x 4 Tb SATA 7200 rpm - $1837
192 Gb 3x 3 Tb NL-SAS 7200 rpm - $1659
192 Gb 3x 4 Tb NL-SAS 7200 rpm - $1879
192 Gb 3x 6 Tb NL-SAS 7200 rpm - $1999
256 Gb 3x 300 Gb 15K - $2089
256 Gb 3x 600 Gb 10K - $2089
256 Gb 3x 2 Tb SATA 7200 rpm - $2079
256 Gb 3x 4 Tb SATA 7200 rpm - $2259
256 Gb 3x 3 Tb NL-SAS 7200 rpm - $2099
256 Gb 3x 4 Tb NL-SAS 7200 rpm - $2289
256 Gb 3x 6 Tb NL-SAS 7200 rpm - $2399
Upgrade from 2 x E5-2640v2 2.0 Ghz to 2x E5-2670v2 2.5
Ghz - $120 per server
Upgrade from 2 x E5-2640v2 2.0 Ghz to 2x E5-2667v2 3.3
Ghz - $300 per server
Optional:
iDRAC 7
enterprise - $ 79
Rapid / Versa rail kit - $ 39
|
|
